Purple Valves
PRPLZ131
1 Piece Hexagon SS Ball Valve 2000PSI
A one-piece hexagon stainless steel ball valve rated to 2000 PSI WOG for corrosion-resistant general service isolation.
Size1/4" to 2"Pressure2000 PSI (WOG)PortReduced PortBodyOne Piece
Manufactured in A351 CF8M (316) stainless steel, this one-piece hexagon ball valve combines a compact, leak-tight body with excellent corrosion resistance for air, water, oil and gas duties. Threaded to ASME B1.20.1 NPT and rated to 2000 PSI WOG, it features an A182 F316 stainless ball and stem with reinforced PTFE seats, providing dependable low-torque quarter-turn shut-off in demanding industrial and process environments.
Specifications
Size Range
1/4" to 2"
Pressure Rating
2000 PSI (WOG)
Temperature Range
-46°C to 232°C (-50°F to 450°F)
End Connections
Threaded ASME B1.20.1 NPT
Body Material
A351 CF8M (316 Stainless Steel)
Ball / Disc / Wedge Material
A182 F316 Stainless Steel
Seat Material
RPTFE
Stem Material
A182 F316 Stainless Steel
Port Type
Reduced Port
Body Style
One Piece
Operation
Lever
Applications
General service, air, water, oil and gas
Design Standard
ASME B16.34, MSS SP-110
Testing Standard
MSS SP-72, API 598
Face to Face Standard
Manufacturer's Standard
Key Features
- Full 316 stainless steel construction for corrosion resistance
- Compact one-piece hexagon body
- Stainless ball and stem with RPTFE seats
- Threaded NPT ends to ASME B1.20.1
- Low-torque quarter-turn operation
Options
- Locking lever handle
- Mounting pad for actuation
- Alternative seat materials
Standards & Certifications
- ASME B16.34
- MSS SP-110
- API 598
- MSS SP-72
Dimensions
| No | Part | Matarial |
| 1 | BODY | ASTM A182 F316 |
| 2 | CAP | SS316 |
| 3 | SEAT | RPTFE |
| 4 | BALL | SS316 |
| 5 | STEM | SS316 |
| 6 | PACKING | PTFE |
| 7 | THRUST WASHER | PTFE |
| 8 | GLAND | SS304 |
| 9 | NUT | SS304 |
| 10 | HANDLE | SS201 |
| 11 | HANDLE COVER | PVC |
| 12 | GASKET | PTFE |
| 13 | SPRING WASHER | SS304 |
| Size | Port | Pressure | d | D | L | H | W | Weight (Lbs) | Torque (in.Lb) |
| 1/4” | RP | 2000PSI | 0.20 | 0.83 | 1.70 | 1.25 | 2.63 | 0.29 | 42 |
| 3/8” | RP | 2000PSI | 0.28 | 0.98 | 1.86 | 1.33 | 2.63 | 0.44 | 42 |
| 1/2” | RP | 2000PSI | 0.36 | 1.18 | 2.46 | 2.19 | 4.65 | 0.71 | 49 |
| 3/4” | RP | 2000PSI | 0.49 | 1.42 | 2.75 | 2.42 | 4.65 | 1.19 | 73 |
| 1” | RP | 2000PSI | 0.63 | 1.81 | 3.38 | 2.57 | 4.72 | 2.09 | 113 |
| 1-1/4” | RP | 2000PSI | 0.79 | 2.17 | 3.69 | 2.90 | 5.75 | 3.09 | 253 |
| 1-1/2” | RP | 2000PSI | 0.96 | 2.40 | 4.00 | 3.10 | 5.75 | 3.75 | 288 |
| 2” | RP | 2000PSI | 1.26 | 2.95 | 4.50 | 3.54 | 6.00 | 6.13 | 391 |
