1PC Standard Port Threaded Ball Valve 2000 PSI
A one piece standard port threaded ball valve, stainless or carbon steel, 1/4 inch to 2 inch, rated 2000 PSI WOG.
Size1/4 inch to 2 inchPressure2000 PSI WOGPortReduced PortBodyTwo Piece
The 1PC Standard Port Threaded Ball Valve offers economical NPT-end isolation for general service, air, water and oil and gas. The one piece body with floating ball seals firmly on RPTFE seats for dependable shut-off. Built to ASME B16.34 and MSS SP-110 in A216 WCB or A351 CF8M, it is rated to 2000 PSI WOG from 1/4 inch to 2 inch in reduced port.
Specifications
Size Range
1/4 inch to 2 inch
Pressure Rating
2000 PSI WOG
Temperature Range
-46°C to 232°C (-50°F to 450°F)
End Connections
Threaded NPT (ASME B1.20.1)
Body Material
A216 WCB / A351 CF8M
Ball / Disc / Wedge Material
A182 F316
Seat Material
RPTFE
Stem Material
A182 F316
Port Type
Reduced Port
Body Style
Two Piece
Operation
Lever
Applications
General Service, Air, Water, Oil and Gas
Design Standard
ASME B16.34, MSS SP-110
Testing Standard
MSS SP-72, API 598
Face to Face Standard
Manufacturer's Standard
Key Features
- Economical threaded NPT ends
- Floating ball for tight shut-off
- RPTFE seats
- Stainless or carbon steel
- Reduced port
Options
- Body: WCB or CF8M
- Seat: RPTFE
Standards & Certifications
- ASME B16.34
- MSS SP-110
- API 598
