Purple Valves
PRPLZ025
2 Piece Carbon Steel Ball Valve 3000PSI
A two-piece carbon steel ball valve rated to 3000 PSI WOG with full-port flow for higher-pressure general service.
Size1/4" to 4"Pressure3000 PSI (WOG)PortFull PortBodyTwo Piece
Engineered for higher-pressure isolation, this two-piece full-port carbon steel ball valve carries a 3000 PSI WOG rating on an A216 WCB body. Threaded to ASME B1.20.1 NPT, it uses an A182 F316 stainless ball and stem with reinforced PTFE seats to deliver bubble-tight shut-off for air, water, oil and gas. The serviceable bolted construction simplifies inspection and seat replacement throughout the valve's life.
Specifications
Size Range
1/4" to 4"
Pressure Rating
3000 PSI (WOG)
Temperature Range
-46°C to 232°C (-50°F to 450°F)
End Connections
Threaded ASME B1.20.1 NPT
Body Material
A216 WCB (Carbon Steel)
Ball / Disc / Wedge Material
A182 F316 Stainless Steel
Seat Material
RPTFE
Stem Material
A182 F316 Stainless Steel
Port Type
Full Port
Body Style
Two Piece
Operation
Lever
Applications
General service, air, water, oil and gas
Design Standard
ASME B16.34, MSS SP-110
Testing Standard
MSS SP-72, API 598
Face to Face Standard
Manufacturer's Standard
Key Features
- 3000 PSI WOG higher-pressure rating
- Full-port body for unrestricted flow
- A216 WCB carbon steel construction
- Stainless ball and stem with RPTFE seats
- Serviceable two-piece design
Options
- Locking lever handle
- Mounting pad for actuation
- Alternative seat materials
Standards & Certifications
- ASME B16.34
- MSS SP-110
- API 598
- MSS SP-72
Dimensions
| No | Part | Matarial |
| 1 | BODY | ASTM A216 WCB |
| 2 | SEAT | DELRIN, PEEK |
| 3 | BALL | SS316 |
| 4 | WASHER | SS316 |
| 5 | BONNET | ASTM A216 WCB |
| 6 | GASKET | SS304 |
| 7 | WASHER | GRAPHITE |
| 8 | STEM | SS316 |
| 9 | PACKING | RPTFE |
| 10 | GLAND | SS304 |
| 11 | HANDLE | SS201+PVC |
| 12 | NUT | A2-70 |
| Size | Port | Pressure | d | L | H | S | M | E |
| 1/4” | FP | 3000PSI | 10 | 76 | 62 | 36 | M5 | 145 |
| 3/8” | FP | 3000PSI | 12.7 | 76 | 62 | 36 | M5 | 145 |
| 1/2” | FP | 3000PSI | 12.7 | 90 | 62 | 36 | M5 | 145 |
| 3/4” | FP | 3000PSI | 19 | 100 | 73 | 42 | M5 | 180 |
| 1” | FP | 3000PSI | 25 | 118 | 80 | 50 | M6 | 190 |
| 1-1/2” | FP | 3000PSI | 38 | 135 | 115 | 70 | M8 | 250 |
| 2” | RP | 3000PSI | 38 | 140 | 115 | 70 | M8 | 250 |
