2 Piece Ductile Iron Ball Valve 2000PSI
Two-piece ductile iron di floating ball valve rated 1000 PSI (WOG) - 2000 PSI(WOG) for oilfield isolation service in 1" to 4" threaded sizes.
The 2 Piece Ductile Iron Ball Valve 2000Psi is a rugged two-piece floating ball valve engineered for hydrocarbon isolation duty on wellheads, oil-patch manifolds and oilfield production lines. Machined from Ductile Iron DI with a 400 series stainless steel ball and 400 series stainless steel stem, the valve seals against RPTFE seats to deliver tight bubble-tight shut-off across a working range of 1000 PSI (WOG) - 2000 PSI(WOG). Available in 1" to 4" sizes with Threaded ASME B1.20.1 NPT / API 5B LP end connections and full port/ reduced port bore options, it offers the corrosion resistance and pressure containment demanded by upstream oil and gas service, with a temperature capability of -46°C to 232°C (-50°F to 450°F). Designed to ASME B16.34, MSS SP-110, API 6D, API 608 and tested to MSS-SP72, API 598, it provides dependable, low-torque on/off control for crude, produced water, gas and general field media.
Specifications
Key Features
- Two-piece floating ball design for reliable bubble-tight shut-off
- Ductile Iron DI body built for oilfield pressure containment
- 400 SERIES STAINLESS STEEL ball and 400 SERIES STAINLESS STEEL stem for wear and corrosion resistance
- RPTFE seats suited to crude, gas and produced-water service
- Threaded ASME B1.20.1 NPT / API 5B LP connections for direct field tie-in
- Working pressure up to 1000 PSI (WOG) - 2000 PSI(WOG)
Options
- Full port or reduced port bore
- Threaded NPT or API 5B LP / EUE end connections
- Lever or gear operation
- Locking handle device
Standards & Certifications
- ASME B16.34, MSS SP-110, API 6D, API 608
- MSS-SP72, API 598
Dimensions
| No | Part | Matarial |
| 1 | BODY | ASTM A395 DI |
| 2 | BODY SEAL | VITON |
| 3 | BOONET | ASTM A395 DI |
| 4 | SEATS | PTFE+15%GF |
| 5 | BALL | SS420, SS304, SS316 |
| 6 | STEM | ASTM A276 420 |
| 7 | THRUST BEARING | PTFE |
| 8 | STEM SEAL | VITON |
| 9 | STEM SEAL | VITON |
| 10 | STEM BEARING | PTFE |
| 11 | STOP PLATE | CS+Ni |
| 12 | PIN WITH CHAIN | STAINLESS STEEL |
| 13 | RETAINER RING | SPRING STEEL |
| 14 | STOP PIN | SPRING STEEL |
| 15 | HEXAGON BOLTS | CARBON STEEL |
| 16 | GREASE ZERK | CARBON STEEL |
| 17 | HANDLE | DUCTILE IRON |
| Size | Port | Pressure | L | H | d | NPT | Lo | Weight (Lbs) | Torque (in.Lb) |
| 1” | FP | 2000PSI | 4.02 | 3.43 | 1 | 11.5 | 6.7 | 4.25 | 710 |
| 2” | FP | 2000PSI | 6 | 5.51 | 2 | 11.5 | 10 | 17.97 | 900 |
| 2-1/2” | FP | 2000PSI | 7 | 6.35 | 2.56 | 8 | 15 | 28.99 | 1200 |
| 3” | FP | 2000PSI | 8.74 | 6.77 | 2.99 | 8 | 15 | 42.33 | 3600 |
| 4” | FP | 2000PSI | 9.38 | 9.11 | 3.94 | 8 | 31.5 | 43.65 | 3600 |
