Purple Valves
PRPLZ080
3PC Forged Steel Threaded Ball Valve 6000 PSI
A three piece forged steel ball valve with NPT or socket weld ends, 1/2 inch to 2 inch, high pressure rated.
Size1/2 inch to 2 inchPressureUp to 6000 PSI WOGPortFull Port / Reduced PortBodyThree Piece
The 3PC Forged Steel Threaded Ball Valve offers a swing-out three piece body for in-line maintenance and seat replacement without removing the valve from the pipe. Forged A105, LF2 or CF8M construction with NPT or socket weld ends suits high pressure process and instrument duties. Built to ASME B16.34 and API 607, the floating ball seals on Delrin or PEEK seats from 1/2 inch to 2 inch in full or reduced port.
Specifications
Size Range
1/2 inch to 2 inch
Pressure Rating
Up to 6000 PSI WOG
Temperature Range
-46°C to 232°C (-50°F to 450°F)
End Connections
Threaded NPT / Socket Weld (SW)
Body Material
A105 / LF2 / A351 CF8M (forged steel)
Ball / Disc / Wedge Material
A182 F316
Seat Material
Delrin / PEEK
Stem Material
A182 F316
Port Type
Full Port / Reduced Port
Body Style
Three Piece
Operation
Lever
Applications
Process, Instrument, Oil and Gas, General Service
Design Standard
ASME B16.34, API 607
Testing Standard
MSS SP-72, API 598
Face to Face Standard
Manufacturer's Standard
Key Features
- Swing-out three piece body for in-line service
- Forged steel construction
- NPT or socket weld ends
- Fire-safe to API 607
- Delrin / PEEK seats
Options
- Body: A105, LF2 or CF8M
- Ends: NPT or socket weld
- Port: full or reduced
Standards & Certifications
- ASME B16.34
- API 607 Fire-Safe
- API 598
