Purple Valves
PRPFL008
Air Valve 02 Combination Kinetic Air Release Valve Thread End
Threaded combination kinetic air release valve for pipelines DN15 to DN50.
Size1/2" to 2" (DN15-DN50)PressurePN10/PN16 (16 bar max)
The Air Valve 02 combination kinetic air release valve provides both large-orifice air discharge during filling and small-orifice release of accumulated air under pressure, in a compact thread-end body for sizes 1/2" to 2". Threads to EN 1074 in BSP or NPT, rated PN16 to 100°C.
Specifications
Size Range
1/2" to 2" (DN15-DN50)
Pressure Rating
PN10/PN16 (16 bar max)
Temperature Range
Up to 100°C
End Connections
Threaded BSP/NPT to EN 1074
Applications
Water and wastewater, irrigation, pumping stations, municipal infrastructure, fire protection
Key Features
- Combination kinetic and automatic air release
- Sizes 1/2" to 2"
- BSP or NPT threads to EN 1074
- Maximum working pressure 16 bar
- Maximum working temperature 100°C
