Purple Valves
PRPLJ034
American Standard High Pressure Cast Steel Globe Valve
A high-pressure American Standard cast steel globe valve for severe-service steam and process throttling at elevated class ratings.
Size1/2" to 16"PressureASME Class 900 to 2500BodyHigh-pressure globe, bolted bonnet, OS&Y
CategoriesGlobe Valves
This high-pressure American Standard cast steel globe valve is rated to high ASME classes for severe-service steam and process throttling. The robust bolted bonnet, OS&Y stem and renewable seat rings provide durable, repeatable control under demanding pressure and temperature conditions in power and petrochemical plants.
Specifications
Size Range
1/2" to 16"
Pressure Rating
ASME Class 900 to 2500
End Connections
Flanged RTJ / Butt-weld
Body Material
Cast carbon / alloy steel (WCB / WC6 / WC9)
Body Style
High-pressure globe, bolted bonnet, OS&Y
Operation
Handwheel / gear / actuated
Applications
Severe-service steam and high-pressure process throttling
Design Standard
ASME B16.34 / API 623
Key Features
- High ASME class ratings
- Renewable seat rings
- Alloy steel options for high temperature
- Durable severe-service design
