Ductile Iron Threaded Ball Valves 1000PSI 2000PSI
Two-piece ductile iron di floating ball valve rated 1000 PSI (WOG) - 2000 PSI(WOG) for oilfield isolation service in 1" to 4" threaded sizes.
The Ductile Iron Threaded Ball Valves 1000Psi 2000Psi is a rugged two-piece floating ball valve engineered for hydrocarbon isolation duty on wellheads, oil-patch manifolds and oilfield production lines. Machined from Ductile Iron DI with a 400 series stainless steel ball and 400 series stainless steel stem, the valve seals against RPTFE seats to deliver tight bubble-tight shut-off across a working range of 1000 PSI (WOG) - 2000 PSI(WOG). Available in 1" to 4" sizes with Threaded ASME B1.20.1 NPT / API 5B LP end connections and full port/ reduced port bore options, it offers the corrosion resistance and pressure containment demanded by upstream oil and gas service, with a temperature capability of -46°C to 232°C (-50°F to 450°F). Designed to ASME B16.34, MSS SP-110, API 6D, API 608 and tested to MSS-SP72, API 598, it provides dependable, low-torque on/off control for crude, produced water, gas and general field media.
Specifications
Key Features
- Two-piece floating ball design for reliable bubble-tight shut-off
- Ductile Iron DI body built for oilfield pressure containment
- 400 SERIES STAINLESS STEEL ball and 400 SERIES STAINLESS STEEL stem for wear and corrosion resistance
- RPTFE seats suited to crude, gas and produced-water service
- Threaded ASME B1.20.1 NPT / API 5B LP connections for direct field tie-in
- Working pressure up to 1000 PSI (WOG) - 2000 PSI(WOG)
Options
- Full port or reduced port bore
- Threaded NPT or API 5B LP / EUE end connections
- Lever or gear operation
- Locking handle device
Standards & Certifications
- ASME B16.34, MSS SP-110, API 6D, API 608
- MSS-SP72, API 598
Dimensions
| Product Information | |
|---|---|
| Type | Floating |
| Size | 1”2”3”4” I |
| Port | Reduced |
| Style | 2 Piece |
| Trim | Chrome Plated Ball & Carbon Steel Stem |
| End Connection | Threaded |
| Pressure/Class | 800PSI 1000 PSI 1500PSI |
| Body Spec | A395 |
| Body Material | Ductile Iron |
| Compliance | Fire Safe |
| Soft Goods | Buna-N Seals |
| Seat Material | Nylon |
| Special Service Conditions | Fire Safe |
| Operation | Manual |
| Series | DIBV |
