Purple Valves
PRPLZ186
Flanged Dual Plate Check Valve
A flanged dual-plate check valve using two spring-loaded plates to stop reverse flow quickly and automatically.
Size2" to 48"PressureANSI Class 150 to 1500PortFull portBodyDual-plate (flanged)
This flanged dual-plate check valve delivers reliable, fast non-return performance with the convenience of bolted flange connections. A pair of spring-loaded half-plates hinged on a central pin opens under forward flow and closes simultaneously on a torsion spring when flow reverses, limiting slamming and water hammer. The flanged body provides a secure, fully retained installation, making it well suited to pump discharge, water treatment and general industrial process lines.
Specifications
Size Range
2" to 48"
Pressure Rating
ANSI Class 150 to 1500
Temperature Range
-46°C to 232°C (-50°F to 450°F)
End Connections
Flanged Raised Face
Body Material
Cast steel / stainless (WCB, CF8M, 2205 and special grades)
Ball / Disc / Wedge Material
Twin spring-loaded plates (dual disc)
Seat Material
Metal or soft seat
Port Type
Full port
Body Style
Dual-plate (flanged)
Operation
Automatic (non-return)
Applications
Pump discharge, water treatment and general industrial process lines
Design Standard
API 594, API 6D
Testing Standard
API 598
Face to Face Standard
ASME B16.10
Key Features
- Twin spring-loaded plates for non-slam closure
- Flanged raised face ends for secure installation
- Compact, lightweight body
- Automatic, fast-acting non-return action
- Low pressure drop
Options
- NACE compliant trim
- Special materials on request
- Soft or metal seating
Standards & Certifications
- API 598
- NACE compliant (optional)
- API 594
