Purple Valves
PRPLZ021
Floating Top Entry Ball Valve
A top-entry floating ball valve designed for in-line maintenance, rated from Class 150 to Class 2500.
Size2" to 6"PressureANSI Class 150 to 2500PortFull Port / Reduced PortBodyTop Entry
CategoriesBall Valves
The top-entry construction of this floating ball valve allows the internals to be inspected and serviced without removing the valve from the pipeline, a major advantage in welded or hard-to-access systems. Spanning Class 150 to Class 2500 with flanged ASME B16.5 ends, it handles a 2" to 6" size range with full-port or reduced-port bores. PTFE, RPTFE, PEEK and Delrin seat options suit a wide span of process conditions.
Specifications
Size Range
2" to 6"
Pressure Rating
ANSI Class 150 to 2500
Temperature Range
-46°C to 232°C (-50°F to 450°F)
End Connections
ASME B16.5
Body Material
A351 CF8M / A216 WCB
Ball / Disc / Wedge Material
SS304 / SS316
Seat Material
PTFE , RPTFE,PEEK,DELRIN
Stem Material
SS304 / SS316
Port Type
Full Port / Reduced Port
Body Style
Top Entry
Operation
Gearbox, Actuator
Applications
General Service, Air, Water, Oil & Gas
Design Standard
ASME B16.34 , ASME B16.5 , API 6D
Testing Standard
MSS SP-72, API 598
Face to Face Standard
ASME B16.10
Key Features
- Reliable bubble-tight shut-off
- Top Entry body construction
- Full Port / Reduced Port bore
- Blow-out proof stem with anti-static device
- Fire-safe and corrosion-resistant materials
Options
- Range of seat materials (RPTFE, PTFE, PEEK, Delrin)
- Lever, gearbox, pneumatic or electric actuation
- Locking handle and stem extensions
- Oxygen-cleaned and special-service preparation
Standards & Certifications
- ASME B16.34
- MSS SP-110
- API 598 Tested
