Series H142X
PRPLJ044
H142X Hydraulic Water Level Control Valve
A hydraulically operated water level control valve that holds tank level between setpoints with smooth, non-slamming float-pilot control.
SizeDN50 to DN600PressurePN10 / PN16BodyDiaphragm hydraulic control valve
The H142X hydraulic water level control valve maintains tank and reservoir levels using a hydraulically actuated diaphragm main valve controlled by a float or level pilot. It opens to refill as the level drops and closes drip-tight at the upper setpoint, delivering reliable, surge-free automatic level management.
Specifications
Product Code
H142X
Size Range
DN50 to DN600
Pressure Rating
PN10 / PN16
End Connections
Flanged
Body Material
Ductile iron, epoxy coated
Body Style
Diaphragm hydraulic control valve
Operation
Float/level pilot, hydraulically actuated
Applications
Automatic tank and reservoir level control
Design Standard
GB/T, manufacturer standard
Key Features
- Hydraulic float-pilot level control
- Non-slam operation
- Drip-tight shut-off
- Adjustable level setpoints
