Purple Valves
PRPLZ196
High Pressure Inline Check Valve 6000PSI
An oilfield high pressure inline check valve 6000psi for non-return / backflow prevention in oil and gas and high pressure service.
Size1/8" , 1/4" ,1/2" ,3/4",1"Pressure6000 PSI (WOG)PortReduced PortBodyTwo Piece
The High Pressure Inline Check Valve 6000PSI is a non-return check valve for oilfield and high pressure service, allowing flow in one direction and closing automatically to prevent backflow. Built for oil and gas, oilfield and general high pressure duties, it offers reliable sealing across its rated size and pressure range.
Specifications
Size Range
1/8" , 1/4" ,1/2" ,3/4",1"
Pressure Rating
6000 PSI (WOG)
Temperature Range
-46°C to 232°C (-50°F to 450°F)
End Connections
Threaded ASME B1.20.1 NPT
Body Material
A182 F316
Ball / Disc / Wedge Material
A182 F316
Seat Material
Viton , HNBR
Port Type
Reduced Port
Body Style
Two Piece
Operation
Automatic (non-return)
Applications
General Service, Air, Water, Oil & Gas
Design Standard
ASME B16.34
Testing Standard
MSS-SP72,API 598
Face to Face Standard
Manufacturers Standard
Key Features
- Automatic non-return / backflow prevention
- Oilfield & high pressure service
- Forged or cast body
Standards & Certifications
- API 6D
- API 598
Dimensions
| Description | Material |
| Body Inlet | SS316 |
| Spring | SS304 |
| Ball | SS304 |
| O-Ring | VITON |
| Packing | SS316 |
| Body outlet | SS316 |
