Pneumatic Threaded Ball Valve
A pneumatically actuated three-piece threaded ball valve for automated on/off control in general service lines.
This three-piece ball valve is paired with a pneumatic actuator to deliver fast, repeatable open and close cycles for automated process control. The valve body is available in A351 CF8M stainless or A216 WCB carbon steel, with an SS316 or SS304 ball and stem and PTFE or RPTFE seats. Sizes range from 1/4 inch to 4 inch with NPT, BSP, BSPT or ISO 7-1 threaded ends and full or reduced port options. Rated to 1000 PSI WOG, it suits general service, air, water and oil and gas systems that call for remote or sequenced operation.
Specifications
Key Features
- Pneumatic rack-and-pinion actuation
- Three-piece body for in-line maintenance
- Stainless or carbon steel construction
- Full and reduced port configurations
Options
- Double-acting or spring-return actuator
- Solenoid and limit switch packages
- Full or reduced port
Standards & Certifications
- ASME B16.34, MSS SP-110
- MSS SP-72, API 598
