Thread Flange
A threaded flange with an internal tapered thread that screws onto the pipe, allowing a bolted connection without any welding.
The threaded flange carries an internal tapered thread, typically to ASME B1.20.1 NPT, so it can be screwed directly onto matching male pipe to create a bolted flange joint without welding. Built to ASME B16.5 dimensions, it suits situations where welding is impractical or prohibited, such as some utility, low-pressure and hazardous-area lines, and it allows the flange to be removed for maintenance. The machined raised or flat face takes a standard gasket, providing a serviceable connection on small to moderate diameter piping.
Specifications
Key Features
- Internal NPT thread screws onto pipe with no welding
- Removable for maintenance and rework
- Suited to areas where welding is restricted
- Machined sealing face for standard gaskets
- Carbon and stainless steel options
Options
- Faces: RF, FF
- Classes: 150, 300, 600, 900, 1500, 2500
- Materials: A105, A182 F304/F316
Standards & Certifications
- ASME B16.5
- ASME B1.20.1
- ASTM A105 / A182
