Three-Piece Threaded Floating Ball Valves 3000 WOG
A three-piece threaded floating ball valve rated to 3000 PSI WOG for general and oilfield isolation duty.
This three-piece floating ball valve combines a robust forged body with a swing-out centre section that lets the seats, ball and seals be serviced in line without disturbing the connected pipework. Bodies are offered in A351 CF8M stainless, A105 carbon and LF2 low-temperature steel, with an A182 F316 ball and stem and Delrin or PEEK seats selected to suit the service. Threaded or socket-weld ends in sizes from 1/2 inch to 2 inch make it a versatile isolation choice for general service, air, water and oil and gas applications at working pressures up to 3000 PSI.
Specifications
Key Features
- Three-piece bolted body for in-line maintenance
- Forged steel and stainless body options
- Floating ball design with fire-safe-capable construction
- Full and reduced port configurations
Options
- Socket-weld or NPT threaded ends
- Delrin or PEEK seats
- Locking handle or actuator mounting
Standards & Certifications
- ASME B16.34, API 607
- MSS SP-72, API 598
Dimensions
| SIZE RANGE | NPS 1/2″ – 2″ (DN 15MM – 50MM) |
| PRESSURE CLASS | ASME 800LB / 3000PSI |
| END CONNECTION | SOCKET, SCREWED, WELD END |
| Material | CARBON STEEL(A105,LF2), STAINLESS STEEL(SS316), ALLOY STEEL, NICKEL ALLOY STEEL |
| DESIGN | API 608, BS EN ISO 17292 |
| TESTING | API598, BS EN 12266-1 |
